Ceramic Capacitor IPC-1752
Our material declarations are created in the IPC-1752 Standard documentation. Ensuring compliance with RoHS and REACH guidelines.
Information is conveniently categorized by product series, with each product size listed. Click the download button to the right for immediate access.
For any data not readily available,
Request Here
Note: if the file is not viewable in browser, please download the pdf and open in files.
| PART NUMBER | SIZE | DIELECTRIC | IPC DOWNLOAD |
|---|---|---|---|
| AGC0201X7R | 0201 | X7R | |
| AGC0402C0G | 0402 | C0G | |
| AGC0402X7R | 0402 | X7R | |
| AGC0402C0G | 0402 | C0G | |
| AGC0603C0G | 0603 | C0G | |
| AGC0603X7R | 0603 | X7R | |
| AGC0805C0G | 0805 | C0G | |
| AGC0805X7R | 0805 | X7R | |
| AGC1206C0G | 1206 | C0G | |
| AGC1206X7R | 1206 | X7R | |
| AGC1210C0G | 1210 | C0G | |
| AGC1210X7R | 1210 | X7R |
| PART NUMBER | SIZE | DIELECTRIC | IPC DOWNLOAD |
|---|---|---|---|
| FTC0402C0G | 0402 | C0G | |
| FTC0402X7R | 0402 | X7R | |
| FTC0603C0G | 0603 | C0G | |
| FTC0603X7R | 0603 | X7R | |
| FTC0805C0G | 0805 | C0G | |
| FTC0805X7R | 0805 | X7R | |
| FTC1206C0G | 1206 | C0G | |
| FTC1206X7R | 1206 | X7R | |
| FTC1210C0G | 1210 | C0G | |
| FTC1210X7R | 1210 | X7R | |
| FTC1808C0G | 1808 | C0G | |
| FTC1808X7R | 1808 | X7R | |
| FTC1812C0G | 1812 | C0G | |
| FTC1812X7R | 1812 | X7R | |
| FTC1825C0G | 1825 | C0G | |
| FTC2220C0G | 2220 | C0G | |
| FTC2220X7R | 2220 | X7R |
| PART NUMBER | SIZE | IPC DOWNLOAD |
|---|---|---|
| C0201HQN | 0201 | |
| C0402HQN | 0402 | |
| C0603HQN | 0603 | |
| C0805HQN | 0805 |
| PART NUMBER | SIZE | DIELECTRIC | IPC DOWNLOAD |
|---|---|---|---|
| HVC0201X7S | 0201 | X7S | |
| HVC0603C0G | 0603 | C0G | |
| HVC0603X7R | 0603 | X7R | |
| HVC0805C0G | 0805 | C0G | |
| HVC0805X7R | 0805 | X7R | |
| HVC1206C0G | 1206 | C0G | |
| HVC1206X7R | 1206 | X7R | |
| HVC1210C0G | 1210 | C0G | |
| HVC1210X7R | 1210 | X7R | |
| HVC1808C0G | 1808 | C0G | |
| HVC1808X7R | 1808 | X7R | |
| HVC1812C0G | 1812 | C0G | |
| HVC1812X7R | 1812 | X7R |
| PART NUMBER | SIZE | DIELECTRIC | IPC DOWNLOAD |
|---|---|---|---|
| C01005X5R | 01005 | X5R | |
| C0201C0G | 0201 | C0G | |
| C0201X5R | 0201 | X5R | |
| C0201X6S | 0201 | X6S | |
| C0201X7R | 0201 | X7R | |
| C0201X7S | 0201 | X7S | |
| C0402X6S | 0402 | X6S | |
| C0402X7R | 0402 | X7R | |
| C0402Y5V | 0402 | Y5V | |
| C0402C0G | 0402 | C0G | |
| C0402X5R | 0402 | X5R | |
| C0603C0G | 0603 | C0G | |
| C0603X5R | 0603 | X5R | |
| C0603C0G | 0603 | C0G | |
| C0603X5R | 0603 | X5R | |
| C0603X6S | 0603 | X6S | |
| C0603Y5V | 0603 | Y5V | |
| C0603X7R | 0603 | X7R | |
| C0805C0G | 0805 | C0G | |
| C0805X6S | 0805 | X6S | |
| C0805Y5V | 0805 | Y5V | |
| C0805Z5U | 0805 | Z5U | |
| C0805X5R | 0805 | X5R | |
| C0805X7R | 0805 | X7R | |
| C1206C0G | 1206 | C0G | |
| C1206X5R | 1206 | X5R | |
| C1206X6S | 1206 | X6S | |
| C1206X7R | 1206 | X7R | |
| C1206Y5V | 1206 | Y5V | |
| C1206Z5U | 1206 | Z5U | |
| C1210C0G | 1210 | C0G | |
| C1210X6S | 1210 | X6S | |
| C1210Z5U | 1210 | X7R | |
| C1210X7S | 1210 | X7S | |
| C1210Y5V | 1210 | Y5V | |
| C1210X5R | 1210 | X5R | |
| C1812C0G | 1812 | C0G | |
| C1812X5R | 1812 | X5R | |
| C1812X7R | 1812 | X7R | |
| C1812Y5V | 1812 | Y5V | |
| C1812Z5U | 1812 | Z5U | |
| C2220X7R | 2220 | X7R |
| PART NUMBER | SIZE | DIELECTRIC | T Value | IPC DOWNLOAD |
|---|---|---|---|---|
| SAFC1808C0G | 1808 | C0G | 2.0±0.2mm | |
| SAFC1808NP0 | 1808 | NPO | 2.0±0.2mm | |
| SAFC1812NP0 | 1812 | NPO | 2.0±0.2mm | |
| SAFC1812X7R | 1812 | X7R | 1.6±0.2mm | |
| SAFC1812X7R | 1812 | X7R | 1.25±0.2mm | |
| SAFC1812X7R | 1812 | X7R | 2.0±0.2mm | |
| SAFC2208NP0 | 2208 | NPO | 1.25±0.2mm | |
| SAFC2208NP0 | 2208 | NPO | 2.0±0.2mm | |
| SAFC2208X7R | 2208 | X7R | 2.0±0.2mm | |
| SAFC2211NP0 | 2211 | NPO | 1.6±0.2mm | |
| SAFC2211X7R | 2211 | X7R | 1.6±0.2mm | |
| SAFC2211X7R | 2211 | X7R | 1.25±0.2mm | |
| SAFC2211NP0 | 2211 | NPO | 1.25±0.2mm | |
| SAFC2211NP0 | 2211 | NPO | 2.0±0.2mm | |
| SAFC2211X7R | 2211 | X7R | 2.0±0.2mm | |
| SAFC2211NP0 | 2211 | NPO | 2.8±0.2mm | |
| SAFC2211X7R | 2211 | X7R | 2.8±0.2mm | |
| SAFC2220NP0 | 2220 | NPO | 1.25±0.2mm |
