High Frequency Passives
Are you designing advanced RF systems or high-speed communication devices?
We're excited to showcase our comprehensive range of High Frequency Components, designed to meet your advanced application needs with exceptional performance and reliability.
Venkel provides quality components with excellent customer service. We can provide cost savings and shorter lead times for these in demand high frequency components.
TRUsTED BY:
| PART NUMBER | SIZE | ATTENUATION | TOLERANCE | |
|---|---|---|---|---|
| PCAT0404X-000PT | 0404 | 0dB | - | View Series Datasheet |
| PCAT0404X-0R5AT | 0404 | 0.5dB | ±0.1dB | |
| PCAT0404X-1R0BT | 0404 | 1dB | ±0.3dB | |
| PCAT0404X-1R5BT | 0404 | 1.5dB | ±0.3dB | |
| PCAT0404X-2R0BT | 0404 | 2dB | ±0.3dB | |
| PCAT0404X-3R0BT | 0404 | 3dB | ±0.3dB | |
| PCAT0404X-4R0BT | 0404 | 4dB | ±0.3dB | |
| PCAT0404X-5R0BT | 0404 | 5dB | ±0.3dB | |
| PCAT0404X-6R0CT | 0404 | 6dB | ±0.4dB | |
| PCAT0404X-7R0CT | 0404 | 7dB | ±0.4dB | |
| PCAT0404X-8R0CT | 0404 | 8dB | ±0.4dB | |
| PCAT0404X-9R0CT | 0404 | 9dB | ±0.4dB | |
| PCAT0404X-100CT | 0404 | 10dB | ±0.4dB | |
| PCAT0404X-110DT | 0404 | 11dB | ±0.8dB | |
| PCAT0404X-120DT | 0404 | 12dB | ±0.8dB | |
| PCAT0404X-130DT | 0404 | 13dB | ±0.8dB | |
| PCAT0404X-140ET | 0404 | 14dB | ±1.0dB | |
| PCAT0404X-150FT | 0404 | 15dB | ±1.5dB | |
| PCAT0404X-160FT | 0404 | 16dB | ±1.5dB | |
| PCAT0404X-170GT | 0404 | 17dB | ±2.0dB | |
| PCAT0404X-180GT | 0404 | 18dB | ±2.0dB | |
| PCAT0404X-190GT | 0404 | 19dB | ±2.0dB | |
| PCAT0404X-200HT | 0404 | 20dB | ±2.5dB |
| PART NUMBER | SIZE | CENTER FREQUENCY | ABSOLUTE GAIN | |
|---|---|---|---|---|
| RFCA0402A1T | 0402 | 2.45GHz | 1dBi | View Datasheet |
| RFCA0805A0T | 0805 | 2.45GHz | 1.32dBi | View Datasheet |
| RFCA0805A3T | 0805 | 2.4GHz | 0.29dBi | View Datasheet |
| RFCA1206E0T | 1206 | 1.575GHz | 1.5-1.7dBi | View Datasheet |
| RFCA1206A5T | 1206 | 2.4GHz | 2.88dBi | View Datasheet |
| RFCA1206Y1T | 1206 | 7.37GHz | 4.5dBi | View Datasheet |
| RFCA1206A1T | 1206 | 2.4GHz | 2dBi | View Datasheet |
| RFCA1206AAT | 1206 | 2.4GHz | 2dBi | View Datasheet |
| RFCA1206A5T | 1206 | 2.4GHz | 2.88dBi | View Datasheet |
| RFCA1206K1T | 1206 | 5GHz | 2.8dBi | View Datasheet |
| RFCA3224YAT | 3224 | 6.5GHz | 4.5dBi | View Datasheet |
| RFCA3708A0T | 3708 | 2.4GHz | 2dBi | View Datasheet |
| PART NUMBER | QTY PER | SIZE | VALUE RANGE | RATE VOLTAGE | TOLERANCE | # OF VALUES | |
|---|---|---|---|---|---|---|---|
| C0201-HQNCAPKIT-10 | 10 | 0201 | 0.1pF to 33pF | 25V | ±0.10pF, ±0.25pF, ±5% | 33 | View Values List |
| C0402-HQNCAPKIT-10 | 10 | 0402 | 0.1pF to 22pF | 50V | ±0.10pF, ±0.25pF, ±5% | 34 | View Values List |
| C0603-HQNCAPKIT-10 | 10 | 0603 | 0.3pF to 47pF | 250V | ±0.10pF, ±0.25pF, ±5% | 35 | View Values List |
| C0805-HQNCAPKIT-10 | 10 | 0805 | 0.9pF to 100pF | 250V | ±0.10pF, ±0.25pF, ±5% | 36 | View Values List |
| PART NUMBER | QTY PER | SIZE | VALUE RANGE | RATED CURRENT | TOLERANCE | |
|---|---|---|---|---|---|---|
| ACWI0806 | 10 | 0806 | 5.5nH to 19.4nH | 2.9A | ±2%, ±5% | View Series Datasheet |
| ACWI0807 | 10 | 0807 | 6.9nH to 22.0nH | 2.7A | ±2%, ±5% | |
| ACWI0908 | 10 | 0908 | 8.1nH to 27.3uH | 4.4A | ±2%, ±5% |
| PART NUMBER | QTY PER | SIZE | VALUE RANGE | TOLERANCE | # OF VALUES | |
|---|---|---|---|---|---|---|
| LMCI0201-KIT-10 | 10 | 0201 | 1.0nH to 33nH | ±0.3nH , ±5nH | 19 | View Values List |
| LMCI1005-KIT-10 | 10 | 1005 (0402) | 1.2nH to 100nH | ±0.3nH , ±5nH | 18 | View Values List |
| LMCI1608-KIT-10 | 10 | 1608 (0603) | 1.5nH to 100nH | ±0.3nH , ±5nH | 21 | View Values List |
| PART NUMBER | QTY PER | SIZE | VALUE RANGE | TOLERANCE | # OF VALUES | |
|---|---|---|---|---|---|---|
| WRFI0402-KIT-10 | 10 | 0402 | 1.6nH to 120nH | ±5% , ±10% | 46 | View Values List |
| WRFI0603-KIT-10 | 10 | 0603 | 1.0nH to 470nH | ±10% | 61 | View Values List |
| WRFI0805-KIT-10 | 10 | 0805 | 2.7nH to 4.7uH | ±10% | 61 | View Values List |
| PART NUMBER | QTY PER | SIZE | POWER RATING | RESISTANCE | TOLERANCE | |
|---|---|---|---|---|---|---|
| HFTF0402 | 10 | 0402 | 1/20W | 10Ω to 1KΩ | ±0.1% - ±1% | View Series Datasheet |
| HFTF0603 | 10 | 0603 | 1/8W | 10Ω to 1KΩ | ±0.1% - ±1% | |
| HFTF0805 | 10 | 0805 | 1/5W | 10Ω to 1KΩ | ±0.1% - ±1% | |
| HFTF1206 | 10 | 1206 | 1/3W | 10Ω to 1KΩ | ±0.1% - ±1% |
| PART NUMBER | QTY PER | SIZE | POWER RATING | RESISTANCE | TOLERANCE | |
|---|---|---|---|---|---|---|
| MEHF0102 | 10 | 0102 | 1/5W - 3/10W | 10Ω to 1KΩ | ±1% - ±2% | View Series Datasheet |
| MEHF0204 | 10 | 0204 | 1/4W - 2/5W | 10Ω to 1KΩ | ±1% - ±2% | |
| MEHF0207 | 10 | 0207 | 1/2W - 1.0W | 10Ω to 1KΩ | ±1% - ±2% |
A LOOK INSIDE OUR KITS
STREAMLINED PROTOYPING
quickly and efficiently prototype your electronic designs
TIME SAVINGS
EACH COMPONENT FEATURES AN INDIVIDUAL BARCODE THAT PROVIDES INSTANT ACCESS TO DETAILED SPECS, DATASHEETS ETC.
COST EFFICIENT
avoid unnecessary expenses on bulk purchasing or ordering components individually
HIGH QUALITY
ensuring reliable performance and reducing the chances of failure, leading to more successful designs
WHY GET AN ENGINEERING KIT?
CLEAN.
FORGET CLUTTERED DRAWERS.
THIS BINDER IS METICULOUSLY ORGANIZED TO MAXIMIZE YOUR SHELF SPACE AND save TIME.
FUNCTIONAL.
PASSIVES AT YOUR FINGERTIPS
A ONE-STOP SOLUTION THAT ELIMINATES THE NEED FOR TIME-CONSUMING SEARCHES FOR INDIVIDUAL COMPONENTS
EXTENSIVE.
THE POWER OF CHOICE.
WITH A VERSATILE SELECTION OF PASSIVES, YOU CAN CONFIDENTLY CHOOSE THE IDEAL COMPONENTS TAILORED TO YOUR NEEDS
WHY GET AN ENGINEERING KIT?
CLEAN.
FORGET CLUTTERED DRAWERS.
THIS BINDER IS METICULOUSLY ORGANIZED TO MAXIMIZE YOUR SHELF SPACE AND MINMIZE WASTED TIME.
FUNCTIONAL.
INFORMATION AT YOUR FINGERTIPS.
A ONE-STOP SOLUTION THAT ELIMINATES THE NEED FOR TIME-CONSUMING SEARCHES FOR INDIVIDUAL COMPONENTS
EXTENSIVE.
THE POWER OF CHOICE.
WITH A VERSATILE SELECTION OF PASSIVES, YOU CAN CONFIDENTLY CHOOSE THE IDEAL COMPONENTS TAILORED TO YOUR NEEDS
EXPERIENCE THE DIFFERENCE
As a supplier of Surface Mount Components for over 35 years, Venkel possesses a breadth of experience and capabilities to serve the needs of manufacturers of any size from prototype through production quantities.
SEE MORE KITS
FREE
10 - 20 COMPONETS PER PART NUMBER
UP TO 50 DIFFERENT PART NUMBERS
FAST SHIPPING WITHIN LEAD TIME
SEE MORE KITS
INTRO KIT
BEST SELLER
INTRODUCTION TO DESIGN
*****
THE INTRO TO DESIGN KIT INCLUDES A WIDE REANGE OF COMPONTNETS. PERFECT FOR THE BEGINNERS.
INCLUDES:
ceramic capacitors (high value & High-Q)
resistors (thick and thin film
inductors (power & rf)
Ferrite beads
leds
$60
FREE
US VS. THEM
VENKEL
Big Box Distributors
FACTORY DIRECT PRICING
YES
NO
IN-HOUSE ENGINEERING SUPPORT
YES
YES
CUSTOM SUPPLY CHAIN SERVICES
YES
NO
1-1 ACCOUNT SUPPORT
YES (Everyone!)
YES (Only for Large Customers)
PROTOTYPE TO PRODUCTION QTYS
YES
YES (It's Expensive)
OUR STORY
As a trusted partner, Venkel provides the electronic component industry with competitive pricing, efficient delivery, and optimized supply chain services. Our extensive inventory and competitive lead times guarantee quick access to components, ensuring seamless production workflows.
With our in-house engineering team, we offer expert support, including free kits, samples, and a comprehensive technical library. Our dedicated account team ensures personalized assistance, while our flexible quantities, cut tape options, and supply chain programs cater to varying production requirements.
As an industry-leading manufacturer, we offer a comprehensive portfolio of Surface Mount Components, including:
Ceramic Capacitors, Choke Coils, Diodes, Engineering Kits, Ferrite Beads, Inductors, LEDs, Resistors, Resistor Arrays, Tantalum Capacitors, and Thermistors.
PARTNERS
Matt Ho
" Venkel is always easy and pleasant to work with. Tech and sales support are readily available whenever I needed help. The Engineering Kits are huge time savers when it comes to prototype tuning and rework. Venkel is my top choice and go-to company for passives; it does not get much easier than dealing with Venkel. "
Senior Electrical Engineer / iRhythm Technologies, Inc.
Louis-Philippe Tremblay
" Quickest component company to respond to requests and provide quality support. Our favorite kits in the lab and cross-referencing support that makes including them in a BOM easy. "
System Engineer / FLIR Systems
Dan Meier
" I find the Venkel staff very helpful. Excellent engineering support very knowledgeable, and responsive. We have one of Venkel’s Engineering resistor kit that we use all the time. Venkel differs from other component suppliers, I Found Venkel more responsive and knowledgeable. "
Principal Engineer / Excelitas
Bella Young
" ... Free kits are constantly updated, any samples we need for our quick prototype needs are promptly mail directly to us. Venkel provides an excellent support to our Contract Manufacturers (CMs) domestically and all over the world. They're technical expertise is available and we engage them very early in our design stages insuring proper pipeline flow of product.
Masimo and/or CMs Purchasing and Venkel’s sales support have a very unique manufacturer to end user relationship not easily found these days of an impersonal cyber world. "
Component Engineer / Masimo
